Jiangsu Silver& Tin Thread Hi-temperature Wire and Cables Co., Ltd. Bahay / Mga produkto / Renewable Energy Cable / Wind Power Cable
Jiangsu Silver& Tin Thread Hi-temperature Wire and Cables Co., Ltd.
Wind Power Cable Custom
  • Wind Power Cable
  • Wind Power Cable
  • Wind Power Cable
  • Wind Power Cable

Wind Power Cable


Proseso ng Paggawa:
Modelo ng Produkto: TC-ER 600V
Na-rate na Temperatura: 90°C
Na-rate na Boltahe: 600V
Sumusunod na Pamantayan: UL1277, ROHS Compliant
Konduktor: Na-stranded na 18-4/0AWG na tinned copper wire
Pagkakabukod: XLPE

Application:
Angkop para sa wind power generation wires
Konstruksyon ng Cable:
Konduktor: Multi-stranded soft annealed copper wire, ASTM Class B8B
Insulation: Polyvinyl chloride (PVC) na may nylon coating/XLPE
Ground Wire: Multi-stranded soft annealed copper wire, ASTM Class B8B
Konstruksyon ng Cable: Three-core/multi-core conductors with full filler between insulated conductors. Nylon ripcord inside the jacket for easy stripping.
Jacket: PVC na lumalaban sa init, moisture, at sinag ng araw (magagamit ang LSOH material).
Konduktor
Kulay: Itim, available ang iba pang mga kulay.

Pagtatanong Ngayon
  • Mga pagtutukoy, istraktura at teknikal na mga parameter:

    Uri ng UL

    Bilang ng mga core

    konduktor

    pagkakabukod

    jacket

    Pinakamataas na resistensya ng konduktor sa 20 ℃

    TC

    AWG

    Numero ng kawad/diameter ng kawad

    Numero ng kawad/diameter ng kawad

    Kapal (mm)

    Panlabas na diameter (mm)

    Kapal (mm)

    Panlabas na diameter (mm)

    2

    18

    16/0.254

    1.16

    0.76

    2.80

    1.14

    1.90

    16

    26/0.254

    1.49

    0.76

    3.10

    1.14

    8.50

    14

    41/0.254

    1.87

    0.76

    3.50

    1.14

    9.30

    12

    65/0.254

    2.36

    0.76

    4.00

    1.14

    10.30

    3

    18

    16/0.254

    1.16

    0.76

    2.80

    1.14

    8.50

    TC

    16

    26/0.254

    1.49

    0.76

    3.10

    1.14

    9.10

    14

    41/0.254

    1.87

    0.76

    3.50

    1.14

    9.90

    12

    65/0.254

    2.36

    0.76

    4.00

    1.14

    11.00

    4

    18

    16/0.254

    1.16

    0.76

    2.80

    1.14

    9.10

    16

    26/0.254

    1.49

    0.76

    3.10

    1.14

    9.80

    14

    41/0.254

    1.87

    0.76

    3.50

    1.14

    10.80

    12

    65/0.254

    2.36

    0.76

    4.00

    1.14

    12.00

    5

    18

    16/0.254

    1.16

    0.76

    2.80

    1.14

    9.90

    16

    26/0.254

    1.49

    0.76

    3.10

    1.14

    10.70

    14

    41/0.254

    1.87

    0.76

    3.50

    1.14

    11.80

    12

    65/0.254

    2.36

    0.76

    4.00

    1.14

    13.10

Tungkol sa Amin
Jiangsu Silver& Tin Thread Hi-temperature Wire and Cables Co., Ltd.
Jiangsu Silver& Tin Thread Hi-temperature Wire and Cables Co., Ltd., is China Wind Power Cable Manufacturer and Custom Wind Power Cable Suppliers, founded in Taizhou, Jiangsu Province in 1994, successfully registered the "Yuanzhi" trademark in 2002. The company specializes in the production and R&D of high-quality high-temperature cables. Its products primarily use Teflon, silicone rubber, flame-retardant polyethylene, and fire-resistant mica tape as insulation materials, and pure nickel, silver-plated, nickel-plated, tin-plated, and oxygen-free bare copper wire as conductors. The production process involves more than twenty steps, including wire bundling, cabling, stranding, extrusion, rubber extrusion, shielding, braiding, and coating. The company manufactures nearly a thousand specifications across eight major series, including cables for electrical equipment, control systems, signal transmission, computers, compensation, fire resistance, high and low temperature resistance, and high voltage resistance. Currently, it has the production capacity for conductor cross-sections up to 400mm², voltage up to 100kV, and temperature ratings from -65°C to +1200°C.
Ang mga produkto ng aming kumpanya ay ginawa ayon sa mga advanced na internasyonal at pambansang pamantayan. Ang base ng produksyon sa istilong hardin nito ay nakapasa sa ISO9001 na sertipikasyon ng sistema ng pamamahala ng kalidad at isang negosyong "Comprehensive Quality Management Standard Compliance" na pinatunayan ng Ministri ng Agrikultura. Ang aming mga produkto ay nakatanggap ng sertipikasyon sa kalidad ng CCC, UL na sertipikasyon sa kaligtasan (USA), at kinilala bilang isang "Sikat na Produkto ng Mga Empresa sa Township sa Lalawigan ng Jiangsu." Naipasa nila ang buong sampling inspeksyon na isinagawa ng National Wire and Cable Testing Center, Provincial Quality Supervision and Testing Center, at Taizhou Municipal Bureau of Quality and Technical Supervision. Nakalista bilang isang "Key Protected Product ng Taizhou City," ang aming mga produkto ay ginagamit ng malalaking negosyo tulad ng Chunlan at mga high-tech na field gaya ng 95856th Unit ng Ministry of Aerospace Industry. Ang ilang mga produkto ay iniluluwas. Upang higit pang ipakita ang aming pangako sa pagbibigay ng kapayapaan ng isip sa aming mga customer, ang aming mga produkto ay nakaseguro sa People's Insurance Company ng China sa loob ng maraming taon. Kami ay isang kumpanya na "ginagalang ang mga kontrata at tumutupad ng mga pangako."
Ang aming kumpanya ay patuloy na susunod sa patakaran sa kalidad ng "maselan na kontrol sa kalidad, hindi natitinag na pangako sa mga customer, at teknolohikal na pagsulong para sa pag-unlad ng negosyo," na may "kasiyahan ng customer" bilang aming gabay na prinsipyo, at komprehensibong palawakin ang "Yuanzhi" na negosyo.
